RPZ30 series Distribution Box

RPZ30 series distribution box (modular combined electrical appliance) is widely used in the lighting and small-capacity power lines of hotels, hotels, families, hospitals, residential quarters, industrial and mining enterprises and civil buildings. It can also be used for overload, short circuit, leakage protection and electric energy measurement, and can also be used for infrequent switching on and off of lighting lines, daily life appliances and small-capacity motors under normal conditions.

The product conforms to: GB/T17466, 1-2008 GB/T17466, 24-2008 standards

Send email to us Download as PDF

Product Detail

Application

Parameters

Samples & Structures

Dimensions

Product Introduction

The product conforms to: GB/T17466, 1-2008 GB/T17466, 24-2008 standards

Features

1.Easy disassembly and assembly of electrical components

2.Electrical components can be matched freely

3.Equipped with common zero terminal block and protective ground terminal block

4.Compatible with wiring in different directions

Ambient temperature: -15~+40℃, the 24-hour average does not exceed +35℃.

Altitude: The altitude of the installation site does not exceed 2000m

Maximum temperature during house construction: +60°C

Operation Condition

1. Ambient temperature: – 15 ~ +40℃, the average value of 24 hours shall not exceed +35℃

2. Altitude: The altitude of the installation site shall not exceed 2000m.

3. Atmospheric conditions: the relative humidity of the air at the installation site shall not exceed 50% when the ambient maximum temperature is+40C, and the relative humidity shall not exceed 50% when the moon is wet

4. The maximum relative humidity of the month is 90% when the average minimum temperature is +25℃

5. Maximum temperature during building:+60℃

Technical Parameter

1. Rated voltage: 400V

2. Rated current: 125A

3. Enclosure protection grade: IP30

4. Maximum power consumption capacity (w): see Table (1)

Maximum number of circuits	4	6	8	10	12	15	18	20	24	30	36	45
Maximum power consumption capacity (w)	20	20	20	20	20	20	20	20	20	20	20	20

Structural features

The box and cover of this product are made of high-quality cold-rolled steel plate, and there are small doors on the box cover; The original electrical appliance is a modular electrical appliance with a width of 18 mm (or an integral multiple of 18), which is installed on the clamping rail. It is convenient and quick to disassemble and assemble, and can be combined as needed.

The box body is equipped with a common neutral terminal block (neutral wire) and a protective grounding terminal block. The upper, lower and rear ends of the box are provided with knock-out holes to meet the requirements of wiring in different directions

Overall and lnstallation Dimensions

4，6, 8, 10, 12, 15, 18 circuit concealed type

20, 24, 30, 45 circuit concealed type

4, 6, 8, 10, 12, 15, 18 circuit surface mounted

20, 24, 30, 45 circuit surface mounted

Number of Circuits	Concealed panel size		Dimensions of open (concealed) box		Surface mounting hole size
	A	B	C	D	E	F
4	175	155	150	130	90	70
6	225	198	200	173	105	83
8	225	245	200	220	105	130
10	285	289	260	263	150	138
12	285	325	260	300	150	174
15	285	379	260	353	150	227
18	285	433	260	408	150	282
20 Single Circuits	285	469	260	444	150	318
20 Double Circuits	485	289	460	263	350	138
24 Double Circuits	325	325	460	300	350	174
30 Double Circuits	379	379	460	353	350	227
36 Double Circuits Circuits	433	433	460	408	350	282
45 Three Circuits	379	379	665	353	555	227
